Classification of shelves by loading.counter top rack price

　　1: Light shelf

　　Insert combination structure, standard group plug -in, no connection bolt, convenient and fast disassembly, super strong closed -mouth steel layer structure, layer height can be arbitrarily adjusted every 50mm, each layer maximum load 150-250 kg.

　　2: Medium -sized shelves

　　The shelves adopt a structure form combined with the beam and the layer plate, which can carry 300-500kg. The beam has a variety of specifications of sections. The structural components can be freely installed.

　　3: Heavy shelves

　　The structure form combined with the beam and the column, the single layer can reach 1-3 tons with weight, can be stored in a tray, or a layer plate can be used. The shelves can be freely disassembled and the spacing is 75mm.

　　The technology and safety factor of the shelves:

　　The architecture parts are rolled with steel plates, and the strength and rigidity meet the mechanical industry standards. Carbon dioxide gas protection welding and automatic welding. The accessories are processed by the four processes of oil removal, rust, pickling, and phosphorus before fuel injection. 180 degrees of epoxy resin pouring (Polyester Powder Coating), generally 60-80 microns.

　　The beam variable bending ratio after bearing is 1: 200, the tolerance is 10%, and the safety factor after bearing is 1.5 times.
